| Type | Horizontal Water-Cooled, 4-Cycle Diesel Engine | |
| Number of Cylinder | 1 | |
| Bore x Stroke | mm(in) | 80 x 75 (3.15 x 2.95) |
| Displacement | cc (cu. in) | 376 (22.95) |
| Maximum Output | hp/rpm | 7.0 / 2400 |
| kW/rpm | 5.22 / 2400 | |
| Continous Rated Output | hp/rpm | 6.0 / 2200 |
| kW/rpm | 4.47 / 2200 | |
| Combustion System | Three Vortex Combustion System | |
| Compression Ratio | 24 | |
| Direction of Rotation | Counter Clockwise (facing flywheel) | |
| Starting System | Manual Speed-Double Handle | |
| Lubricant System | Forced Lubrication with Trochoid Pump | |
| Cooling System | Radiator | |
| Fuel | Light Diesel Oil (SAE no.2-D) | |
| Lubricating Oil | API service CC, CD or CF class (SAE #30, 20, 10W-30) | |
| Cooling Water Capacity | L (US gal) | 1.3 (0.34) |
| Fuel Tank Capacity | L (US gal) | 8.0 (2.11) |
| Crankcase Oil Capacity | L (US gal) | 2.0 (0.53) |
| Dry Weight | Kg (lb) | 67 (147.7) |
| Lamp Dynamo Output | V.W | With Lamp 12-32 |
