| 4WD |
| Model | V2403-M-DI-T | ||
| Type | Direct injection, with turbocharger, water-cooled 4-cycle diesel | ||
| No. of cylinder | 4 | ||
| Bore and stroke | mm | 87 x 102.4 | |
| Total displacement | L | 2.434 | |
| Engine gross power* | kW (HP / PS) | 42.6 (57.1) | |
| Engine net power* | kW (HP / PS) | 40.7 (54.5) | |
| Power Drive Shaft (PTO Shaft)* | kW (HP / PS) | 36.4 (48.9) | |
| Rated revolution | rpm | 2400 | |
| Maximum torque | N-m | 213.8 | |
| Battery | V | 12V 55Ah | |
| Fuel | Diesel Fuel | ||
| Fuel tank | L | 65 | |
| Engine crankcase (with filter) | L | 7.6 | |
| Engine coolant | L | 9 | |
| Transmission case | L | 46 | |
| Overall length (without 3p) | mm | 3250 | |
| Overall width | mm | 1950 | |
| Overall height (w/ ROPS) | mm | 2450 | |
| Wheel base | mm | 2050 | |
| Min. ground clearance | mm | 415 | |
| Tread | Front | mm | 1445, 1475, 1560, 1590, 1645, 1675, 1755, 1785 |
| Rear | mm | 1520, 1630, 1710, 1820 | |
| Weight | kg | 2350 | |
| Tire | Front | 9.50-24 | |
| Rear | 16.9-28 | ||
| Steering | Hydrostatic power steering | ||
| Transmission | Gear shift, 8 forward and 8 reverse | ||
| Brake | Mechanical, Wet disk type | ||
| Min. turning radius (with brake) | m | 3 | |
| Clutch | Dry type | ||
| Hydraulic control system | Position, draft (top link sensing) and mix control | ||
| Pump capacity | L / min | 30.5 | |
| System pressure | MPa (kgf / cm) | 19.0 (193) | |
| 3-point hitch | Category 2 | ||
| At lift points | kg | 1800 | |
| 24 in. (610 mm) behind lift points | kg | 1550 | |
| Rear PTO | 6-splines | ||
| PTO / Engine speed | rpm | 540/2258, 750/2196 | |
| Work Lamp | Can cover wider range |
| Overheat Alarm | Buzzer sound |
| Operator Seat | Newly- designed seat wider and has suspension that absorbs vibration. |
| Bottle Holder | |
| Rollover Protection System (ROPS) |
| Overall length (without 3p) | mm | 3250 | |
| Overall width | mm | 1950 | |
| Overall height (w/ ROPS) | mm | 2450 | |
| Wheel base | mm | 2050 | |
| Min. ground clearance | mm | 415 | |
| Tread | Front | mm | 1445, 1475, 1560, 1590, 1645, 1675, 1755, 1785 |
| Rear | mm | 1520, 1630, 1710, 1820 | |
| Weight | kg | 2350 | |
| Overall length (without 3p) | mm | 3250 | |
| Overall width | mm | 1950 | |
| Overall height (w/ ROPS) | mm | 2450 | |
| Wheel base | mm | 2050 | |
| Min. ground clearance | mm | 415 | |
| Tread | Front | mm | 1445, 1475, 1560, 1590, 1645, 1675, 1755, 1785 |
| Rear | mm | 1520, 1630, 1710, 1820 | |
| Weight | kg | 2350 | |
| Overall length (without 3p) | mm | 3250 | |
| Overall width | mm | 1950 | |
| Overall height (w/ ROPS) | mm | 2450 | |
| Wheel base | mm | 2050 | |
| Min. ground clearance | mm | 415 | |
| Tread | Front | mm | 1445, 1475, 1560, 1590, 1645, 1675, 1755, 1785 |
| Rear | mm | 1520, 1630, 1710, 1820 | |
| Weight | kg | 2350 | |
