| 4WD |
| Model | V3307-DI | ||
| Type | Direct injection, liquid cooled 4 cylinder diesel | ||
| No. of cylinder | 4 | ||
| Bore and stroke | mm | 94 x 120 | |
| Total displacement | L | 3.331 | |
| Engine gross power* | kW (HP / PS) | ||
| Engine net power* | kW (HP / PS) | 50.7(68/68.9) | |
| Power Drive Shaft (PTO Shaft)* | kW (HP / PS) | 46.2 (61.95/62.81) | |
| Rated revolution | rpm | 2600 | |
| Maximum torque | N-m | 232 | |
| Battery | 12V, RC: 160 min, CCA 900A | ||
| Fuel | Diesel | ||
| Fuel tank | L | 65 | |
| Engine crankcase (with filter) | L | 11 | |
| Engine coolant | L | 8 | |
| Transmission case | L | 56 | |
| Overall length (without 3p) | mm | 3,445 | |
| Overall width | mm | 1,860 | |
| Overall height (w/ ROPS) | mm | 2,265 | |
| Wheel base | mm | 2,050 | |
| Min. ground clearance | mm | 415 | |
| Tread | Front | mm | 1520 |
| Rear | mm | 1520-1720 | |
| Weight | kg | 2,090 | |
| Tire | Front | 9.5-24 | |
| Rear | 16.9-30 | ||
| Steering | Hydraulic Power Steering | ||
| Transmission | Gear shift, 8 forward and 8 reverse | ||
| Brake | Multiple wet discs mechanical | ||
| Min. turning radius (with brake) | m | ||
| Clutch | Dry single plate | ||
| Hydraulic control system | Position, draft (top link sensing) and mix control | ||
| Pump capacity | L / min | 41.6 | |
| System pressure | MPa (kgf / cm) | 19.1 (195) | |
| 3-point hitch | Category 1 and 2 | ||
| At lift points | kg | 2,300 | |
| 24 in. (610 mm) behind lift points | kg | 1,800 | |
| Rear PTO | 6-splines | |
| PTO / Engine speed | rpm | 540 / 2205 |
| Overall length (without 3p) | mm | 3,445 | |
| Overall width | mm | 1,860 | |
| Overall height (w/ ROPS) | mm | 2,265 | |
| Wheel base | mm | 2,050 | |
| Min. ground clearance | mm | 415 | |
| Tread | Front | mm | 1520 |
| Rear | mm | 1520-1720 | |
| Weight | kg | 2,090 | |
| Overall length (without 3p) | mm | 3,445 | |
| Overall width | mm | 1,860 | |
| Overall height (w/ ROPS) | mm | 2,265 | |
| Wheel base | mm | 2,050 | |
| Min. ground clearance | mm | 415 | |
| Tread | Front | mm | 1520 |
| Rear | mm | 1520-1720 | |
| Weight | kg | 2,090 | |
| Overall length (without 3p) | mm | 3,445 | |
| Overall width | mm | 1,860 | |
| Overall height (w/ ROPS) | mm | 2,265 | |
| Wheel base | mm | 2,050 | |
| Min. ground clearance | mm | 415 | |
| Tread | Front | mm | 1520 |
| Rear | mm | 1520-1720 | |
| Weight | kg | 2,090 | |
