| 4WD |
| Model | V3307-DI-TI | ||
| Type | Vertical, Water-Cooled, 4-cycle diesel engine | ||
| No. of cylinder | 4 | ||
| Bore and stroke | mm | 100 x 120 | |
| Total displacement | L | 3.769 | |
| Engine gross power* | kW (HP / PS) | 80.53(108/109.5) | |
| Engine net power* | kW (HP / PS) | 79.4(106.5/108) | |
| Power Drive Shaft (PTO Shaft)* | kW (HP / PS) | 79.4 (106) | |
| Rated revolution | rpm | 2600 | |
| Maximum torque | N-m | 363 | |
| Battery | V | 12V, RC: 160 min, CCA 900A | |
| Fuel | Diesel | ||
| Fuel tank | L | 175 | |
| Engine crankcase (with filter) | L | 10.7 | |
| Engine coolant | L | 9.6 | |
| Transmission case | L | 60 L | |
| Overall length (without 3p) | mm | 4065 | |
| Overall width | mm | 2220 | |
| Overall height (w/ ROPS) | mm | 2675 | |
| Wheel base | mm | 2435 | |
| Min. ground clearance | mm | 435 mm | |
| Tread | Front | mm | 1550, 1650 |
| Rear | mm | 1760 to 2090 | |
| Weight | kg | 3650 | |
| Tire | Front | 13.6-24 | |
| Rear | 18.4-34 | ||
| Steering | Full hydraulic power steering | ||
| Transmission | Hydraulic shuttle shift, fully synchronized main shift, 16F/16R | ||
| Brake | Hydraulic wet disc | ||
| Min. turning radius (with brake) | m | ||
| Clutch | Hydraulic wet disc | ||
| Hydraulic control system | Position, draft (top link sensing) & mix control | ||
| Pump capacity | L / min | 65 | |
| System pressure | MPa (kgf / cm) | 19.6 (200) | |
| 3-point hitch | Category 2 | ||
| At lift points | kg | 2500 | |
| 24 in. (610 mm) behind lift points | kg | 2100 | |
| Rear PTO | 6 spline | |
| PTO / Engine speed | rpm | 540 |
| Overall length (without 3p) | mm | 4065 | |
| Overall width | mm | 2220 | |
| Overall height (w/ ROPS) | mm | 2675 | |
| Wheel base | mm | 2435 | |
| Min. ground clearance | mm | 435 mm | |
| Tread | Front | mm | 1550, 1650 |
| Rear | mm | 1760 to 2090 | |
| Weight | kg | 3650 | |
| Overall length (without 3p) | mm | 4065 | |
| Overall width | mm | 2220 | |
| Overall height (w/ ROPS) | mm | 2675 | |
| Wheel base | mm | 2435 | |
| Min. ground clearance | mm | 435 mm | |
| Tread | Front | mm | 1550, 1650 |
| Rear | mm | 1760 to 2090 | |
| Weight | kg | 3650 | |
| Overall length (without 3p) | mm | 4065 | |
| Overall width | mm | 2220 | |
| Overall height (w/ ROPS) | mm | 2675 | |
| Wheel base | mm | 2435 | |
| Min. ground clearance | mm | 435 mm | |
| Tread | Front | mm | 1550, 1650 |
| Rear | mm | 1760 to 2090 | |
| Weight | kg | 3650 | |
