| 4WD |
| Model | V2403-M-DI | ||
| Type | Direct injection, Vertical, Water-Cooled, 4-cycle diesel | ||
| No. of cylinder | 4 | ||
| Bore and stroke | mm | 87 × 102.4 | |
| Total displacement | L | 2.434 | |
| Engine gross power* | kW (HP / PS) | 38.0(51.0 / 51.7) | |
| Engine net power* | kW (HP / PS) | 36.2(48.5 / 49.2) | |
| Power Drive Shaft (PTO Shaft)* | kW (HP / PS) | 31.7(42.6 / 43.1) | |
| Rated revolution | rpm | 2700 | |
| Maximum torque | N-m | 164 | |
| Battery | 12 V 52 Ah | ||
| Fuel | Diesel fuel No.2-D | ||
| Fuel tank | L | 48 | |
| Engine crankcase (with filter) | L | 7.6 | |
| Engine coolant | L | 7 | |
| Transmission case | L | 40 | |
| Overall length (without 3p) | mm | 3200 | |
| Overall width | mm | 1495 | |
| Overall height (w/ ROPS) | mm | 2049 | |
| Wheel base | mm | 1925 | |
| Min. ground clearance | mm | 400 | |
| Tread | Front | mm | 1150 |
| Rear | mm | 1155, 1225 | |
| Weight | kg | 1493 | |
| Tire | Front | 8-18 | |
| Rear | 13.6 – 26 | ||
| Steering | Hydrostatic power steering | ||
| Transmission | Gear shift, 8 forward and 8 reverse | ||
| Brake | Mechanical, Wet disk type | ||
| Min. turning radius (with brake) | m | 2.65 | |
| Clutch | Dry type Single stage | ||
| Hydraulic control system | Position control | ||
| Pump capacity | L / min | 30.5 | |
| System pressure | MPa (kgf / cm) | 17.7(180) | |
| 3-point hitch | Category 1 | ||
| At lift points | kg | 1300 | |
| 24 in. (610 mm) behind lift points | kg | 1053 | |
| Rear PTO | SAE 1-3 /8, 6-splines | |
| PTO / Engine speed | rpm | 540/2268, 750/2348 |
| Overall length (without 3p) | mm | 3200 | |
| Overall width | mm | 1495 | |
| Overall height (w/ ROPS) | mm | 2049 | |
| Wheel base | mm | 1925 | |
| Min. ground clearance | mm | 400 | |
| Tread | Front | mm | 1150 |
| Rear | mm | 1155, 1225 | |
| Weight | kg | 1493 | |
| Overall length (without 3p) | mm | 3200 | |
| Overall width | mm | 1495 | |
| Overall height (w/ ROPS) | mm | 2049 | |
| Wheel base | mm | 1925 | |
| Min. ground clearance | mm | 400 | |
| Tread | Front | mm | 1150 |
| Rear | mm | 1155, 1225 | |
| Weight | kg | 1493 | |
| Overall length (without 3p) | mm | 3200 | |
| Overall width | mm | 1495 | |
| Overall height (w/ ROPS) | mm | 2049 | |
| Wheel base | mm | 1925 | |
| Min. ground clearance | mm | 400 | |
| Tread | Front | mm | 1150 |
| Rear | mm | 1155, 1225 | |
| Weight | kg | 1493 | |
