| 4WD |
| Model | D1803 | ||
| Type | Direct injection, Vertical, Water-Cooled, 4-cycle diesel | ||
| No. of cylinder | 3 | ||
| Bore and stroke | mm | 87 × 102.4 | |
| Total displacement | L | 1.826 | |
| Engine gross power* | kW (HP / PS) | 23.5 (31.5 / 32.0) | |
| Engine net power* | kW (HP / PS) | 22.4 (30.0 / 30.5) | |
| Power Drive Shaft (PTO Shaft)* | kW (HP / PS) | 20.4(27.4 / 27.8) | |
| Rated revolution | rpm | 2700 | |
| Maximum torque | N-m | 101.1 | |
| Battery | 12 V 52 Ah | ||
| Fuel | Diesel (Supports B7, B10, and B20 Diesel Fuel) | ||
| Fuel tank | L | 40 | |
| Engine crankcase (with filter) | L | 5.7 | |
| Engine coolant | L | 6 | |
| Transmission case | L | 28.5 | |
| Overall length (without 3p) | mm | 2920 | |
| Overall width | mm | 1337 | |
| Overall height (w/ ROPS) | mm | 2010 | |
| Wheel base | mm | 1610 | |
| Min. ground clearance | mm | 330 | |
| Tread | Front | mm | 1020 |
| Rear | mm | 1060 | |
| Weight | kg | 1257 | |
| Tire | Front | 7 – 16 | |
| Rear | 11.2 – 24 | ||
| Steering | Integral type power steering | ||
| Transmission | Gear shift, 8 forward and 8 reverse | ||
| Brake | Wet disk type | ||
| Min. turning radius (with brake) | m | 2.5 | |
| Clutch | Dry type single stage | ||
| Hydraulic control system | Position control | ||
| Pump capacity | L / min | 23.9 | |
| System pressure | MPa (kgf / cm) | 16.2 | |
| 3-point hitch | Category 1 | ||
| At lift points | kg | 651 | |
| 24 in. (610 mm) behind lift points | kg | 16.2 | |
| Rear PTO | SAE 1-3 /8, 6-splines | ||
| PTO/ Engine speed | rpm | 540/2430, 750/2596 | |
| Overall length (without 3p) | mm | 2920 | |
| Overall width | mm | 1337 | |
| Overall height (w/ ROPS) | mm | 2010 | |
| Wheel base | mm | 1610 | |
| Min. ground clearance | mm | 330 | |
| Tread | Front | mm | 1020 |
| Rear | mm | 1060 | |
| Weight | kg | 1257 | |
| Overall length (without 3p) | mm | 2920 | |
| Overall width | mm | 1337 | |
| Overall height (w/ ROPS) | mm | 2010 | |
| Wheel base | mm | 1610 | |
| Min. ground clearance | mm | 330 | |
| Tread | Front | mm | 1020 |
| Rear | mm | 1060 | |
| Weight | kg | 1257 | |
| Overall length (without 3p) | mm | 2920 | |
| Overall width | mm | 1337 | |
| Overall height (w/ ROPS) | mm | 2010 | |
| Wheel base | mm | 1610 | |
| Min. ground clearance | mm | 330 | |
| Tread | Front | mm | 1020 |
| Rear | mm | 1060 | |
| Weight | kg | 1257 | |
