| Overall length | (mm) | 4800 |
| Overall width | (mm) | 2295 |
| Overall height | (mm) | 2830 |
| Weight | (kg) | 3090 |
| Model | Kubota V2403-M-DI-TE-CS2T | |
| Type | Water-cooled 4-cycled 4-cylinder vertical diesel engine (with turbo charger) | |
| Total displacement | (L) | 2.434 |
| Output / Rotation speed | (Kw[PS]/rpm) | 50.7 kW [69.0 PS] / 2700 |
| Fuel tank capacity | (L) | 85 |
| Battery | (V) | 12 |
| Center distance | 1250 mm | |
| Crawler | Width x Ground contact length | 500 x 1700 mm |
| Minimum ground clearance | Minimum ground clearance | 325 mm |
| Speed shift system | HST 3-Range (3F/3R) | |
| Travel Speed | Forward/ Backward | Low: 0 – 0.97 Middle: 0 – 1.37 High: 0 – 1.85 |
| Turning System | Clutch & Break |
|
Reel |
Diameter x Width | (mm) | 900 x 1903 |
| Up / down control | Hydraulic system | ||
|
Cutting width (Distance between the top of divider)
|
(mm) | ||
| Gathering length | (mm) | 2075 | |
| Clutter Bar length | (mm) | 1980 |
| Threshing system | (rpm) | |
| Threshing Cylinder | Diameter x Width | (mm) |
| Revolutions | ||
| Concave area | (m²) | |
| Sorting system |
| Capacity | L | 500 |
| Take-out System | 2 / Bagging |
| Harvesting Capacity | (ha/hr) | 0.3 – 0.62 for Rice |
| Overall length | (mm) | 4800 |
| Overall width | (mm) | 2295 |
| Overall height | (mm) | 2830 |
| Weight | (kg) | 3090 |
| Overall length | (mm) | 4800 |
| Overall width | (mm) | 2295 |
| Overall height | (mm) | 2830 |
| Weight | (kg) | 3090 |
| Overall length | (mm) | 4800 |
| Overall width | (mm) | 2295 |
| Overall height | (mm) | 2830 |
| Weight | (kg) | 3090 |
