| 4WD |
| Model | D1005-E2-D3IT | ||
| Type | E-TVCS, Liquid-cooled, 3 cylinder diesel | ||
| No. of cylinder | 3 | ||
| Bore and stroke | mm | 76 x 73.6 | |
| Total displacement | L | 1001 | |
| Engine gross power* | kW (HP / PS) | 15.7 (21.3) | |
| Engine net power* | kW (HP / PS) | ||
| Power Drive Shaft (PTO Shaft)* | kW (HP / PS) | 12.7 (17.3) | |
| Rated revolution | rpm | 2600 | |
| Maximum torque | N-m | 58.3 | |
| Battery | 50 B24L(S)-MF | ||
| Fuel | |||
| Fuel tank | L | 23 | |
| Engine crankcase (with filter) | L | 3.1 | |
| Engine coolant | L | 3.9 | |
| Transmission case | L | 12.5 | |
| Overall length (without 3p) | mm | 2387 | |
| Overall width | mm | 1000, 910 | |
| Overall height (w/ ROPS) | mm | 1940 | |
| Wheel base | mm | 1560 | |
| Min. ground clearance | mm | 300 | |
| Tread | Front | mm | 705 |
| Rear | mm | 700, 790 | |
| Weight | kg | 615 | |
| Tire | Front | 5-12 | |
| Rear | 8-18 | ||
| Steering | Recirculating ball type manual steering | ||
| Transmission | Gear shift, 9 forward and 3 reverse | ||
| Brake | Wet disc type | ||
| Min. turning radius (with brake) | m | 2.1 | |
| Clutch | Dry single plate | ||
| Hydraulic control system | Position Control | ||
| Pump capacity | L / min | 3P: 16.6 | |
| System pressure | MPa (kgf / cm) | ||
| 3-point hitch | ISO Category 1N | ||
| At lift points | kg | 750 | |
| 24 in. (610 mm) behind lift points | kg | 590 | |
| Rear PTO | SAE 1-3/8, 6 splines | ||
| PTO/ Engine speed | rpm | 540 / 2504, 980 / 2510 | |
| Overall length (without 3p) | mm | 2387 | |
| Overall width | mm | 1000, 910 | |
| Overall height (w/ ROPS) | mm | 1940 | |
| Wheel base | mm | 1560 | |
| Min. ground clearance | mm | 300 | |
| Tread | Front | mm | 705 |
| Rear | mm | 700, 790 | |
| Weight | kg | 615 | |
| Overall length (without 3p) | mm | 2387 | |
| Overall width | mm | 1000, 910 | |
| Overall height (w/ ROPS) | mm | 1940 | |
| Wheel base | mm | 1560 | |
| Min. ground clearance | mm | 300 | |
| Tread | Front | mm | 705 |
| Rear | mm | 700, 790 | |
| Weight | kg | 615 | |
| Overall length (without 3p) | mm | 2387 | |
| Overall width | mm | 1000, 910 | |
| Overall height (w/ ROPS) | mm | 1940 | |
| Wheel base | mm | 1560 | |
| Min. ground clearance | mm | 300 | |
| Tread | Front | mm | 705 |
| Rear | mm | 700, 790 | |
| Weight | kg | 615 | |
